Data / Sample files

Sample files

A real example of each product, exactly as it is delivered. Download one to check the format before you buy.

Velocity Surveys

TXT, LAS, PDF · $50 per well

Download sample (57.1 KB)

The standard delivery package: time-depth pairs (TXT), LAS with interval / average / RMS velocities, and the original scanned survey (PDF). Well 17045200110000.

A	17045200110000
B	HUMBLE O&R	MIAMI CORP /K/
C	0 ft
D	5500 ft/sec
E	0.000	0
E	2.000	7477
E	2.110	7977
E	2.217	8477
E	2.323	8977
E	2.425	9477
E	2.526	9977
E	2.626	10477
E	2.723	10977
E	2.819	11477…

Search velocity surveys · See on the map

Directional Surveys

TXT · $2 per well

Download sample (6.3 KB)

Every station: measured depth, TVD, inclination, azimuth, dX, dY. Well 35077206220000.

# SAMPLE from the GCVD Data Warehouse (velocitydata.com). Provided for evaluation; not for redistribution.
# Directional survey (azimuths recalculated for historical grid convergence)
# API 35077206220000
# ANSONORATION | BUZZARD GAP #1-19 1-19 | Latimer, Oklahoma
# Location (lat, lon, WGS 84): 34.888216, -95.23556  [source NAD83, taken as WGS 84, +/-2 m]
# MD_FT	TVD_FT	INC_DEG	AZI_DEG	DX_FT	DY_FT
0.00	0.00	0.00	0.00	0.00	0.00
250.08	250.00	1.49	39.00	4.60	4.60
343.20	343.00	2.92	39.00	8.00	7.90
435.31	435.00	2.73	39.00	11.00	11.10
528.39	528.00	2.51	37.00	13.40	14.40
620.49	620.00	2.54	35.00	15.50	17.90
713.58	713.00	2.56	33.00	17.20	21.70
807.68	807.00	2.64	30.00	18.60	25.80…

Search directional surveys · See on the map

Digital Well Curves

LAS · $25 per well

Download sample (1.9 MB)

LAS file with SP,ILD,GR,DT,DCAL,NPHI,DPHI,DT1. Well 17001007690000.

~VERSION INFORMATION
 VERS.               2.00:   CWLS LOG ASCII STANDARD - VERSION 2.00
 WRAP.                 NO:   ONE LINE PER DEPTH STEP
~WELL INFORMATION
#MNEM.UNIT      DATA TYPE    INFORMATION
#----------   ------------   ------------------------------
 STRT.F         3039.0000:   START DEPTH
 STOP.F        13110.1807:   STOP DEPTH
 STEP.F            0.5000:   STEP LENGTH
 NULL.          -999.2500:   NO VALUE
 COMP. LYDIA HUNT-HERBERT TRUST:   COMPANY
 WELL.   PERCY JEFFERS #1:   WELL
 FLD .            WILDCAT:   FIELD
 LOC .         20-T8S-R2E:   LOCATION
 STAT.          LOUISIANA:   STATE
 COUN.             ACADIA:   COUNTY…

Search digital well curves · See on the map

Paleontological Data

CSV · $2 per well

Download sample (785 B)

Paleontological picks (CSV). Well 17001005320000.

# SAMPLE from the GCVD Data Warehouse (velocitydata.com). Provided for evaluation; not for redistribution.
# Paleontological picks
# API 17001005320000
# CHEYENNE OIL CORP. OF | DISC SUD;H BIEBER D 001 | Acadia, Louisiana
# Location (lat, lon, WGS 84): 30.4088991, -92.3559325  [source NAD27, converted by NADCON (NGS conus grid); NAD83 taken as WGS 84, +/-2 m]
depth_ft,fossil,eco,strat_comments,lith_comments,eco_comments,sample_comments,source
7630.0,HETEROSTEGINA SP,,,,,,PDI
8070.0,MARGINULINA HOWEI,,,,,,PDI
8295.0,CAMERINA A,,,,,,PDI
8455.0,MIOGYPSINOIDES A,,,,,,PDI
8665.0,CIBICIDES HAZZARDI,,,,,,PDI
8900.0,MARGINULINA TEXANA,,,,,,PDI
9520.0,NONION STRUMA,,,,,,PDI
9585.0,NODOSARIA BLANPIEDI,,,,,,PDI…

Search paleontological data · See on the map

Mud Weight & Temperature

CSV · $1 per well

Download sample (535 B)

Mud weight & temperature readings (CSV). Well 17001006310000.

# SAMPLE from the GCVD Data Warehouse (velocitydata.com). Provided for evaluation; not for redistribution.
# Mud weight & temperature readings
# API 17001006310000
# UNION TEXAS PETR. CORP | MT-4 RB SUA;D COLLIGAN 001 | Acadia, Louisiana
# Location (lat, lon, WGS 84): 30.3901998, -92.2084261  [source NAD27, converted by NADCON (NGS conus grid); NAD83 taken as WGS 84, +/-2 m]
depth_ft,mud_weight_ppg,temperature_f,circ_time_hr
10599.0,13.5,190.0,
12502.0,14.6,230.0,
13012.0,14.5,242.0,
13360.0,16.2,248.0,
13454.0,16.3,250.0,…

Search mud weight & temperature · See on the map

Virtual Checkshots

TXT, LAS · $10 per well

Time-depth pairs (TXT) and LAS with interval / average / RMS velocities, extracted from the GCVD onshore velocity volume at the well. Well 42481345440000.

# Virtual checkshot: time-depth extracted from the GCVD onshore velocity volume at this location (not a measured survey)
# API: 42481345440000
# Operator: NEWFIELD EXPLORATION COMPANY
# Well: PEACH CREEK GAS UNIT #4
# County/Area: Wharton, Texas  Block/Loc: SRV:KUYKENDALL ROBERT #4 ABS:40
# Surface location (lat, lon, WGS 84): 29.3833159, -96.2099303  [source NAD27, converted by NADCON (NGS conus grid); NAD83 taken as WGS 84, +/-2 m]
# TVD (ft): 16338
A	42481345440000
B	NEWFIELD EXPLORATION COMPANY PEACH CREEK GAS UNIT 4
C	0 ft
D
E	0.000	0
E	0.100	269.2
E	0.200	572.6…

At any point on the map (velocity cube)

Download sample (3.8 KB)

Time-depth (TXT) and LAS at 29.30000, -95.90000, interpolated from the GCVD velocity cube, with the control nodes it was blended from. Point P2930000N09590000W.

# Virtual checkshot at a point: time-depth from the GCVD velocity cube (not a measured survey)
# Location (lat, lon): 29.30000, -95.90000
# Cube part: Onshore Texas & Louisiana
# Interpolated from 4 control node(s) within 1.82 km; confidence A, expected error about 1.5%
TWT_ms	Depth_ft
0	0.0
100	281.7
200	593.1
300	926.2
400	1286.7
500	1647.3
600	2015.5
700	2389.8
800	2773.5…

Search virtual checkshots · See on the map · About the velocity cube
